Model: A4AC5036D1000A
Descriptions:
Air Conditioner Condenser Outdoor Unit; Type Split System, Scroll Compressor; Voltage Rating 208/230 Volt AC; Current Rating 14 Amp (MCA), 25 Amp (MOP), 0.9 Amp FLA (Fan), 10.9 Amp RLA/63 Amp LRA (Compressor); Frequency Rating 60 Hertz; Number of Phases 1; Power Rating 1/8 HP; Cooling Capacity 24000 BTU/Hour; Temperature Control Type Thermostat; Operating Temperature 115 Deg F (Ambient); Enclosure Material Heavy Gauge Galvanized Steel; Enclosure Finish Weather Resistant Powder Painted; Size 29-3/4 Inch Width x 29-3/4 Inch Depth x 28-5/8 Inch Height; Weight 162 Pound; Approval UL (Canada and US); Refrigerant Type R-410A; Fan Type Propeller; Motor Type Direct Drive; Coil Type Aluminum; Refrigerant Line Size 3/4 Inch (Gas), 3/8 Inch (Liquid); Energy Efficiency 15 SEER; Number of Compressor 1; Number of Row 1; Number of Speed 1; Fins per Inch 24; Speed Rating 1075 RPM; Noise Level 73 Decibel; Applicable Standard AHRI 210/240/270
Specifications:
Brand
Ameristar Heating And Cooling
Approval
Cooling Capacity
Enclosure Finish
Weather Resistant Powder Painted
Enclosure Material
Heavy Gauge Galvanized Steel
Family
Frequency Rating
Max Fuse Size
Number Of Phases
Operating Temperature
Power Rating
Size
29-3/4 Inch Width X 29-3/4 Inch Depth X 28-5/8 Inch Height
Temperature Control Type
Type
Split System, Scroll Compressor
Voltage Rating
Weight
Documents:
